EW360

Product > FAN > EW360

EW360

model360
Fan Dimensions120*120*25
Fan Speed800-2000RPM +/-10%
Fan Air Flow73.18CFM
Maximum Air Pressuer (mmH2O)2.34mmH2O
Fan MTBF40,000小时
Fan bearingDynamic pressure bearing
Fan Noise Level36.2 Dba
Fan Connector4pin
Rated VoltageDC12V
Input Current0.23A
input Power2.76W
Pump Dimensions76*82*50mm
Size of drain397*120*27mm
Drainage materialAluminium
pump MTBF30,000小时
Pump Niose Level27dBA
Pump Working VoltageDC12V
Pump Current0.3A
Pump Power3.6W
Size of water pipe400*ID∅6.5*OD∅12mm
Pump Speet2400+/-10%
BearingHydraulic
Packing6PCS
MotorThree-phase six-pole motor
Scope of applicationINTEL:LGA115X/1200/1700/1366
INTEL:LGA2011/2066
AMD:FM2/FM2+/AM3/AM3+/AM4/AM5
